Product Specifications 2-11
No. Name Function
<1> Probe cable hook Manage probe cable
<2> Ultrasound main unit Ultrasound system
<3> Ascending/descending switch Press to adjust the height of operation panel
<4> Anti-theft setting Used to fix the ultrasound system to the trolley.
<5> Printer bracket Used to place the printer
Used to extend ports for connecting probes (optional)
<7> Storage tray Used to place the adaptor, gel and other stuff.
<8> USB port Connects USB devices (2 ports)
<9> Probe holder Used to place probes temporarily
<10> Caster
Used for securing or moving the system
Step on the second footswitch to lock the trolley. Step
on the first footswitch to unlock the trolley.
Used to switch audio/video (optional)
<12> Lifting column Used to adjust the height of operation panel
