3-14 System Installation
4. Press scan trigger button to receive barcode when ultrasound device is running (without
installing driving program). For more operation details, see relevant barcode reader manual.
Disconnect the connecting cable
1. Using the tip of a screwdriver or some other tools with a sharp head, depress the cable’s
modular connector clip.
2. Carefully slide out the cable.
3.4.5.3 JADAK Barcode Reader
Supported Barcode Reader Model
The Ultrasound System supports the following barcode readers: HS-1M JDK-2413 and HS-1R
JDK-2601.
Operating System Version
If you need to use the JADAK barcode reader with the Ultrasound System, ensure that the
operating system version is as follows:
PC module (SOM5892-3517-M-8G) 2.0.11 or later versions
PC module (SOM-6897C3-T02A1E) 3.3.13 or later versions
If the version is lower than the requirements, upgrade the operating system.
