4-48
Before upgrading the module software, note the matching between module name and module
code as listed below.
Module name Module code
Monitor module MC
Auxiliary control module MC2
Power board POWER
Electronic flowmeter FLOW
MO2B CO2 0611-MO2B
Main control board FPGA
display drive
FPGA
To upgrade the module software:
1. When selecting the module software upgrade package, confirm the correctness of
checksum and version. You also need to check the module code, as shown below.
2. Other operations are similar to those for booting software upgrade. Refer to
4.4.1.2Booting Software Upgrade to finish the upgrade.
NOTE
z After completing module software upgrade, turn on the anesthesia machine to
confirm the correctness of upgrade software version information.
