3
Used when ON/OFF operation of CHECK value is required.
9
“ENTER” key
Used for registering the set value at the time of various kinds of settings.
10
Position of pasting the Unit seal
As necessity requires, paste the Unit seal attached.
11
Terminals 1
Connects with various kinds of strain gage applied transducer such as load cell, ground earth
wire and DC power supply.
12
Terminals 2
Connects with “RUN” and “ERROR” for open collector output.
13
BCD output connector
Connects with BCD output, “ZERO”, “A/Z”, “A/Z OFF”, “HOLD”, “LOCK”, “SEL1” and
“SEL2” for external control input.
14
Bridge power supply voltage changeover switch
Used when the bridge power voltage is selected from “10 V” and “2.5 V”.
15
DIP switch for P.C. output settings
Used for setting the P.C. output logic and the P.C. width at BCD output.
⑯ DIP switch for operation change when program is written
Use it at the time of the program rewriting.
Do not change the setting. When the setting is changed, it doesn't operate.
Only SW208-1 is turned on when the customer is used, and the other seven poles are turning off.
