7−15. Monitor mode
In Monitor mode, the applied load on the strain gage applied transducer at present can be
displayed after it is converted into the unit of mV/V.
For example, when load cell is used, and the output value is unclear, apply actual load in order to
read the output value at the time of initial load application and also at the time of the maximum
load application by using this function and make calibration with the value as a base.
● The display value in the Monitor mode is a reference value.
The accuracy of display is 0.5 % approximately.
● In Monitor mode, the range which can be monitored is from
−0.4 mV/V to 3.4 mV/V approximately.
● When the “A/Z A ” key is pressed with the load display of “FUNC.”,
the display will change as the following sequence at every time the
key is pressed. “FUNC”→“CCAL”→“A C A L” →“LCAL”→“ZERO”→
“SPAN”→“TARE”→“CHECK”→“MONIT”→“F−END”→“FUNC”→
“CCAL”→･････(Hereinafter, it will repeat.)
