7−13. Memory position for setting data and so on
The instrument memories each data into RAM and EEPROM as follows:
Since the EEPROM is non−volatile, it will be stored almost indefinitely.
Also, RAM is charged by battery. Back−up life will be about 10 years when it is stored in the room
temperature.
1
Data memorized at RAM
D A/Z data A/Z OFF or data clear is possible with the execution of F−98.
D ZERO data Data clear is possible with the execution of F−98.
D Zero tracking data Data clear with the execution of F−98.
2
Data memorized at EEPROM
D FUNC data Possible to initialize data with the execution of F−99.
D Calibration data Possible to re−write by re−calibration.
7−14. Check mode
The following confirmations can be made in the Check mode.
D Check on ROM version
D Check on bridge power supply voltage
D Check on control input
D Check on open collector output
D Check on BCD output
● In the Check mode, the instrument can return to the Measurement
mode on the way by pressing the “FUNC.” key.
