48
6−2−2. Operation in another modes
When the “A/Z OFF Y” key is pressed with the displaying condition of various kinds of set
values, set value makes increment one count by one from 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, and 0 again
continuously.
● In the operation method of the paragraph 6−2−2, when the key is
pressed for more than about 2 s, each operation will be executed
continuously at a constant interval without ON/OFF operation of key.
6−3. “ZERO” key
6−3−1. Operation in the Measurement mode
When the display value on load display is within 10 % against the maximum display value
(R efer to the paragraph 5.), the “0” display will be shown compulsively by the operation due to
the zero set function. As for details, refer to the paragraph 7−9.
6−4. “FUNC.” key
6−4−1. Operation in the Measurement mode
Function mode can be entered, and “FUNC” is shown on load display. From this condition,
setting function or shifting to another mode can be provided. When the “FUNC” key is pressed
during each mode, shifting to the Measurement mode can be available.
6−4−2. Operation in another modes
When the “FUNC” key is pressed in each mode, shifting to the Measurement mode can be
available.
6−5. “CHECK” key
6−5−1. Operation in the Measurement mode
When the CHECK value set with F−43 is ON and the “CHECK” on status display lights on,
load value corresponding to the set value with F−43 will be added to the load display value.
By pressing again, CHECK value will become OFF position and returns to the former condition.
6−5−2. Operation in another modes
(1) Calibration
Set value can be initialized compulsively in each step of calibration procedures.
(2) Function mode
In Function mode, Function No. and set value for Function No. are made to “0” compulsively.
6−6. “ENTER” key
Pressing the “ENTER” key makes the changed set value internally registered, and the condition of
possible to set will be over.
