Minebea CSD-581-15 - 7−2−3. BCD Output Connector Pin Configuration

52
(2) Output data BCD 5 digits of parallel output
POL.(Polarity) output ON at minus, output OFF at plus
P.C.(Print command)
ERROR
OVR.(over)
(3) Input data Refer to the paragraph 7−1−1 External control input signal.
(4) Output target Changeable for display(Setting of F−02), Net weight, Gross weight
and external selection (SEL.1, SEL.2).
SEL.1
SEL.2 Output data
Open Open Display
Short Open A/Z cancelled portion
Open Short Net weight
Short Short Gross weight
(5) Output rate Synchronous with display rate(F−03).
4 times/s, 20 times/s, 50 times/s
7−2−3. BCD output connector pin configuration
1 COM. 13 8×10
2
25 ERROR
2 1×10
0
14 1×10
3
26 P.C.
3 2×10
0
15 2×10
3
27 HOLD
4 4×10
0
16 4×10
3
28 LOCK
5 8×10
0
17 8×10
3
29 SEL.1
6 1×10
1
18 1×10
4
30 SEL.2
7 2×10
1
19 COM. 31 ZERO
8 4×10
1
20 2×10
4
32 A/Z
9 8×10
1
21 4×10
4
33 A/Z OFF
10 1×10
2
22 8×10
4
34 N.C.
11 2×10
2
23 POL. 35 N.C.
12 4×10
2
24 OVR. 36 N.C.
Suitable plug 57−30360 Made by DDK.
 ● Don’t connect with N.C. pins.
