SB−310 Internal terminal connections
To CSD−581−15
Suitable crimp−type
terminal lugs
･Y type
RD
Short bars
Output Port
Input port No. 1
Input Port
No. 4
or
WH
YE
YE
GN
BL
WHGN BLYE
YE
YE
BL
GN
WH
WHGN
BL
BLGN
WH
φA
φB
RD
A：3.2 mm or less
B：7 mm or less
･Round type
RD
RD
RD
A
B
Input port No. 2
Input port No. 3
ii) In case of application of CAB−501(6 cores cable)
※3 (Length of CAB−501 should be
within 100 m totally.)
CAB−501
SB−310
RED
WHT
※1GRN
※1BLU
Shield
ORN
BLK
Enlarged figure for connecting section
RED
WHT
※1BLU
Shield
※1GRN
ORN
BLK
CN202
DIP202
DIP203
