56
(1) Selection of P.C. logic
Selection can be made by the ON/OFF at DIP201:1,2 as the below table.
Negative logic Positive logic
DIP201：1 ON OFF
DIP201：2 OFF ON
Warning ● Never set ON or OFF both of 1 and 2 on DIP201 at the same time.
If neglected, P.C. output will not operate correctly.
(2) Selection of P.C. width
By the ON/OFF operation at 3 and 4 on DIP201, following selection can be made.
Approx. 100 ms Approx. 15 ms Approx. 5 ms
DIP201：3 OFF ON OFF ON
DIP201：4 OFF OFF ON ON
Apply suitable selection corresponding to the display rate set with F−03.
Display
rate
(F−03)
Width of P.C.
Di
sp
l
ay ra
t
e
(F
−
03)
Approx. 100 ms Approx. 15 ms Approx. 5 ms
4 times/s ○ ○ ○
20 times/s × ○ ○
50 times/s × ○ ○
○：Available ×：Unavailable(P.C. output will not operate properly.)
Warning ● For the selection of P.C. width, apply suitable selection corresponding
to the display rate set with F−03. If neglected, P.C. output will not
operate properly.
