– 61 –
IMAGE CORRECTION
Variation Amount Control slider
Limit indication checkbox
In the Colour Balance correction, 6 images that have been corrected by one-step in each red (R),
magenta (M), blue (B), cyan (C), green (G) or yellow (Y) direction from the center image are
displayed. When the image in the direction to be corrected is clicked, the image is placed in
center and new variation images are displayed.
By dragging the Variation Amount Control slider, the value of correction can be changed in the
range from 1 to 20 (The initial value is 10).
When the Limit indication check box is checkmarked and the image is corrected in each red (R),
magenta (M), blue (B), cyan (C), green (G) or yellow (Y) direction, any part of the image which
has been corrected beyond the range which can be displayed is displayed in reversed colour.
VARIATION CORRECTION – COLOUR BALANCE
