MIRCOM TECHNOLOGIES LIMITED, 9500 Series: No Subscriber Line Page 10
NON-SCROLLING DIRECTORY CONTROLLERS:
Model 9501A ± Main Controller.1000 residents capacity.
Model 9502A ± Add-on Controller for auxiliary entrance(s). 1000 residents capacity.
Model 9503 ± Multi-Building Guard House Controller. 1000 residents capacity.
Accessory:
PCB Assy.: MD-345 ± Auxiliary 6 relay board. This module is intended for use of Multiple Building
Application or for applications where relay contacts are required for activation of
peripherals. Please contact our Engineering Field Support Personnel for detailed
wiring scheme and information.
Note: Make sure to order the proper lobby panels meant for non-scrolling directory.
3. DECODER/RELAY CABINETS
Model 9508 ± Decoder/relay cabinet can hold up to eight (8) relay cards or ninety six (96)
telephone lines. Relay cards not included.
Model 9516 ± Decoder/relay cabinet can hold up to sixteen (16) relay cards or one
hundred ninety two (192) telephone lines. Relay cards not included.
Accessories:
Model 9512 ± Relay Card interfaces up to 12 telephone lines.
Model 9512E ± Elevator Recall Relay Card provides up to 12 relay contacts.
Model 9106 ± 6 Ft. Amphenol Cable. Standard for 9500 Series systems. Use this cable
for CA-71A or RJ-71C configured BIX Block.
Model 9106E ± 6 Ft. Amphenol Cable. Use this cable for interfacing the 9500 series systems to
existing RJ-71A configured BIX Block.
Model 9406 ± 6 Ft. Octopus Relay Cable. Use this cable for custom wiring the telephone's Tip
and Ring by using the standard CA-38A (RJ-38A) modular jacks.
4. SITE SELECTION
The Entry Panel should be installed as near as possible to the controlled entry point. Do not install the system in a
location where the LCD display is exposed to direct sunlight since it will reduce visibility.
5. POWER SUPPLY REQUIREMENTS
Select the appropriate power transformers required by your system configuration. Below are the transformer
models that are available:
.
Model PS-4 ± 16 VAC/ 40 VA, CSA approved Class 2 Power Transformer.
Model PS-3B ± 8 VAC/13 VA, 16 VAC/17 VA, 24 VAC/20 VA, CSA approved Class 2 Power
Transformer.
Model PS-13 ± 12VDC, 200mA.
6. WIRING REQUIREMENTS
Count the number of wires and identify the proper gauges that are required for your system configuration. For a
typical Single or Multiple entrance application, please refer to pages 5 and 6. For System Block Diagrams page 7.
For custom applications, we recommend consulting our Application Engineering personnel for evaluation.
