MIRCOM TECHNOLOGIES LIMITED, 9500 Series: No Subscriber Line Page 40
PROGRAMMING INSTRUCTIONS: NON-SCROLLING DIRECTORY
Before programming the system, obtain the required information by using the forms provided in APPENDICES "D-
1 and D-2". Some information may be found on APPENDICES "B-1 and B-2".
The following programming information pertains to both the 9501A and the 9502A unless otherwise specified
After the system initializations (power up), the display should appear as shown below.
<<< MIRCOM >>>
followed by...
Please enter the
Resident Code ...
This is the Normal Mode of the system. The system will accept all valid codes such as Access Codes, Keyless
Entry Codes, and programming Master Code.
Before entering to Programming Mode for the first time, it is recommended to restore the factory default Master
Code *999 by shorting the reset pins for approximately 3 seconds. Please refer to Fig. 18 for location of reset pins.
NOTE: Shorting the reset pins will only restore the factory default Master Code *999 and will not affect any
programmed information.
ENTERING PROGRAMMING MODE
Enter the MASTER CODE (factory default is *999) to enable PROGRAMMING MODE.
The screen should appear ...
PROGRAM MODE
- Please Wait -
for a few seconds and then the display should change to...
> PROGRAM MODE <
Enter code now, or *888 for help ...
This is the Program Mode Menu. At this stage, the system is waiting for valid programming code.
Important note:
Before programming the system for the first time, it is recommended to clear-up all memories and restore all factory defaults by using a special command *5*5 while
at Program Mode menu . Since this special command (*5*5) is a destructive command which can erase all the programmed information without the provision to
undo, the user must take a precaution when using this command.
There are two ways to program the system.
1. By using *888 for Menu Driven type of programming.
2. By using the Direct Access Programming Codes for manual programming. Entering these codes will lead the
user directly to the desired function. The Direct Access Programming Codes are listed on the following table.
To Next Page
