SIP Settings
Prerequisites
• Before configuring SIP settings, ensure that MCD programming is competed. See “MCD
Programming Required (TBD)” on page 74.
• Obtain the Server address name, User Name, and Login Name from the User and Device
Configuration form.
1. Press Settings
2. Press Advanced
3. Press System Settings
4. Press SIP Settings
See the information below for the parameters to configure. For a list of all the settings and their
default options, see the UC360 Engineering Guidelines.
Account
Under Account, set the following parameters:
- Server Address — the IP address (IPv4) or the FQDN format address of the SIP
server.
- Username — the SIP user’s ID. It is the DN (extension number) assigned on the SIP
server.
- Display Name — the displayable caller name, e.g. John Brown.
Authentication
Under Authentication, set the login name and password.
Transport
Under Transport, enable or disable the following setting:
- UDP — the UC360 should be configured for UDP.
- TCP/IP
