Operation in the two conditions described above can be summarised with the chart below:
UR
ambiente
(%)
Differenziale P20.20
Deumidifica
P50.03
Differenziale P20.21
P50.04
Umidifica
5% fisso
Limite setpoint deumidifica
dipendente da setpoint UMIDIFICA
Limite minimo setpoint deumidifica
P14.10
Figure 8-9: chart of management of the limit of the dehumidification setpoint.
The Dehumidification and Humidification setting parameters are under the “Setpoint” menu.
The Dehumidification and Humidification differential parameters are under the “Regulations” menu, which can be accessed
by entering the “Service” password.
The Dehumidify set point minimum limit parameter is under the “Safety” menu, which can be accessed by entering the
“Factory” password.
OBLIGATION:
All changes made to the minimum limit of the dehumidifcation setpoint must be authorised by
MEHITS who will provide the new minimum value to be set for the single unit in use.
