2.5.21 [P31] Alarm out Menu
Accessible from: “User” group.
Mask of the terminal
Description
Par.N.
Alarm out
 
Access mask to “Alarm out” menu (Addressing of alarms on the digital outputs).
Alarm out addressing
--------------- P31.01
Alarm out A
contact logic: _\_
--------------- P31.02
Alarm out B
contact logic: _\_
Logic of alarm contact A.
[NO | NC].
Logic of alarm contact B.
[NO | NC].
31.01
31.02
Alarm out addressing
--------------- P31.03
(003) Presence of
Fire/Smoke: A
Addressing of the Fire/Smoke alarm on digital output.
31.03
Alarm out addressing
--------------- P31.04
(004) Wrong Phase
Sequence or Supply
Out of Limit: A
Addressing of the phase sequence alarm on digital output.
31.04
Alarm out addressing
--------------- P31.10
(101) Loss of Air
Flow: A
Addressing of the Air Flow alarm on digital output.
31.10
Alarm out addressing
--------------- P31.11
(120) Return Temp.
Probe Fail./Disc.: A
Addressing of the return air temperature sensor alarm on digital output.
31.11
Alarm out addressing
--------------- P31.12
(125) Return Humidity
Probe Fail./Disc.: A
Addressing of the humidity sensor alarm of the Return T+H probe on digital output.
31.12
Alarm out addressing
--------------- P31.13
(130) Diff. Pressure
Probe Fail./Disc.: A
Addressing of the differential pressure probe alarm on digital output.
31.13
