Mitsubishi Electric Evolution+ s-MEXT - [P33] Alarm out Menu 2

87
Version 38
2.5.24 [P33] Alarm out Menu 2
Accessible from: “User” group.
Mask of the terminal
Description
Par.N.
Alarm out
2
 
Access mask to “Alarm out 2” menu (Addressing of alarms on the digital outputs).
Alarm out addressing 2
No Alarm out 2
Parameters Available
Mask displayed when none of the parameters of this menu for the unit are available.
Alarm out addressing 2
--------------- P33.15
(151-154) Any Fan -
Offline Alarm: A
--------------- P33.16
(156-159) Any Fan -
Phase Fault: A
Addressing of the fans offline alarms on digital output.
Addressing of the fans phase sequence alarms on digital output.
Visible only on units with EC fans controlled via serial communication.
33.15
33.16
Alarm out addressing 2
--------------- P33.17
(161-164) Any Fan -
Motor Blocked: A
--------------- P33.18
(166-169) Any Fan -
Voltage Problem: A
Addressing of the fan motor blocked alarms on digital output.
Addressing of the fans voltage problem alarms on digital output.
Visible only on units with EC fans controlled via serial communication.
33.17
33.18
Alarm out addressing 2
--------------- P33.19
(171-174) Any Fan -
Heat Problem: A
Addressing of the fans thermal problem alarms on digital output.
Visible only on units with EC fans controlled via serial communication.
33.19
Alarm out addressing 2
--------------- P33.20
(176-179) Any Fan -
Generic Alarm: A
Addressing of the fans generic alarms on digital output.
Visible only on units with ec fans controlled via serial communication or on units on
which the forced nominal speed on fan alarm function is enabled.
33.20
Alarm out addressing 2
--------------- P33.50
(103) Air flow loss
evaporator from fan
alarm output: A
Addressing of the Air Flow alarm due to fan fault on digital output.
33.50
Alarm out addressing 2
--------------- ------
--------------- P33.52
(119) Temperature reg.
out of range out: A
Addressing of the adjustment temperature probe alarm on digital output.
33.52
