Mitsubishi Electric Evolution+ s-MEXT - [P50] Setpoint Menu

90
Version 38
Mask of the terminal
Description
Par.N.
Alarm out addressing 2
---------------P33.91
(050)GasLeakdetected
alarmonoutput:A
Addressing of PAC–IF Client proble alarm (0:A – 1:None – 2:B)
Addressing of PAC–IF Server 1 system alarm (0:A – 1:None – 2:B)
33.91
2.5.25 [P50] Setpoint Menu
Accessible from: “Main” group.
Mask of the terminal
Description
Par.N.
Setpoint
 
Access mask to “Setpoint” menu (Work point).
Setpoint – Active Set
- - - - - - - - - - -
Cooling setpoint:
24.0°C
- - - - - - - - - - -
Heating setpoint:
24.0°C
Active Setpoint display mask.
Setpoint – Edit Set
--------------- P50.01
Cooling set: 24.0°C
HeatSt Active P20.25
|-------|--------|
22.0°C 24.0°C 32.0°C
Parameter for setting the cooling set point.
The parameters that limit the permissible range for the cooling setpoint are
displayed.
The values of the permissible range limits for the cooling setpoint are displayed.
50.01
Unit - Edit Set
--------------- P50.02
Heating set: 22.0°C
P20.26 Active ColdSt
|-------|--------|
12.0°C 22.0°C 24.0°C
Parameter for setting the heating set point.
Visible only when the heating resources are present.
The parameters that limit the permissible range for the heating setpoint are
displayed.
The values of the permissible range limits for the heating setpoint are displayed.
50.02
Setpoint
--------------- P50.03
Dehumidification
setpoint : 55%RH
--------------- P50.04
Humidification
setpoint : 45%RH
Dehumidification setpoint.
Humidification setpoint.
50.03
50.04
Setpoint
--------------- P50.05
Cooling setpoint
with LAN limits:30.0°C
--------------- P50.06
Heating setpoint
with LAN limits:18.0°C
Cooling setpoint during LAN out of range.
Heating setpoint during LAN out of range.
50.05
50.06
