2.5.2 [P10] Config. Menu
Accessible from: “Factory” group.
Mask of the terminal
Description
Par.N.
Config.
 
Access mask to Config. Menu. (Configuration).
Config
--------------- P10.33
Unit type:
Perimetral
- - - - - - - - - - -
Cold type set:
Direct Expansion
Parameter for setting the type of unit.
[Perimetral | Rack Cooler | Cooling Door | Modular Perimetral | TLC]
Displays the type of cooling resources set.
10.33
Config
--------------- P10.35
Amount of CW Circuits:
0
----------------------
----------------------
---------------------
Parameter for setting the number of chilled water circuits.
Parameter for setting the use of a chilled water circuit as an Indirect
Free Cooling circuit.
Displays the type of cooling resources set.
10.35
Config
--------------- P10.36
Amount of DX Circuits:
1
Cold type set:DX
Parameter for setting the number of direct expansion circuits.
Displays the type of cooling resources set.
10.36
Config
-----------------10.54
Condensing unit type:
None/t-Mate
Cold type set:DX
Parameter for setting the type of condensing unit.
[None/t-Mate | HCAT/i-HCAT | m-MOCU | Mr.Slim]
Visible only with at least one direct expansion circuit installed.
10.54
Config
-----------------10.55
MIN time OFF Mr.SLIM:
120s
Cold type set:SM
Minimum off time of Mr. Slim units.
10.55
Config
--------------- P10.10
Internal fan project
speed: 070%
Internal fan project speed.
Visible only on units with EC fans controlled by an analog signal.
10.10
Config.
--------------- P10.11
Maximum reduction of
fan project speed: 20%
Resulting Min speed:
070 – (070x 20%) = 056
Maximum reduction of the project speed (determines the minimum
project speed of the internal fan).
10.11
