Mitsubishi Electric Evolution+ s-MEXT - Page 83

83
Version 38
Mask of the terminal
Description
Par.N.
Alarm out addressing
--------------- P31.14
(140) Supply Air Temp.
Probe Fail./Disc.: A
Addressing of the delivery air temperature probe alarm on digital output.
31.14
Alarm out addressing
--------------- P31.16
(144) Outdoor Air Temp
Probe Fail./Disc.: A
Addressing of the external air temperature probe alarm on digital output.
31.16
Alarm out addressing
--------------- P31.18
(150) Heaters Overheat
or Heaters Contactor
Failed: A
Addressing of the electric heaters alarm on digital output.
31.18
Alarm out addressing
--------------- P31.19
(180) Return T+H Probe
Offline: A
Addressing of the Return T+H probe offline alarm on digital output.
31.19
Alarm out addressing
--------------- P31.23
(192) I/O Expansion 1
Offline: A
--------------- P31.24
(199) Energy Analyzer
Offline: A
Addressing of the I/O expansion 1 offline alarm on digital output.
Addressing of the network analyser offline alarm on digital output.
31.23
31.24
Alarm out addressing
--------------- P31.25
(195) Humidifier Board
Offline: A
Addressing of the humidifier CPY board offline alarm on digital output.
31.25
Alarm out addressing
--------------- P31.42
(402) Humidifier Life
Timer Expired: A
--------------- P31.43
(404) Humidifier
Drain Alarm: A
Addressing of the humidifier life expired alarm on digital output.
Addressing of humidifier discharge fault alarm on digital output.
VIsible only if the internal humidifier type is set.
31.42
31.43
Alarm out addressing
--------------- P31.44
(406) Humidifier
Loss of Water: A
--------------- P31.45
(408) Humidifier
Low Current: A
Addressing of the humidifier insufficient water alarm on digital output.
Addressing of the humidifier electrodes low current alarm on digital output.
VIsible only if the internal humidifier type is set.
31.44
31.45
Alarm out addressing
--------------- P31.46
(410) Humidifier
High Current: A
--------------- P31.47
(412) Humidifier
Generic Alarm: A
Addressing of the humidifier electrodes high current alarm on digital output.
Addressing of the generic humidifier alarm on digital output.
VIsible only if the internal humidifier type is set.
31.46
31.47
