Mitsubishi Electric Evolution+ s-MEXT - Page 67

67
Version 38
Mask of the terminal
Description
Par.N.
Fan
--------------- P23.11
Air pressure diff.
scan time: 060s
--------------- P23.12
Condensation control
enable: N
Interval for acquisition of the air differential pressure.
Enable the condensation control function.
23.11
23.12
Fan
--------------- P23.61
Post-ventilation for
el. Heaters enable: Y
--------------- P23.62
Post-ventilation for
el. Heaters time: 060s
Enable the heater post-ventilation function.
Post-ventilation time.
Visible only if the electric heaters are present.
23.61
23.62
Fan – Const. flow rate
--------------- P23.65
Constant flow rate
regulation setpoint:
02500m3/h
--------------- P23.66
Differential: 025Pa
DeltaP setpoint for Constant Flow adjustment (divided by 100).
DeltaP differential for Constant Flow adjustment.
23.65
23.66
Fan – Const. DeltaP
--------------- P23.67
Constant DeltaP
regulation setpoint:
010Pa
--------------- P23.69
Differential: 05Pa
DeltaP setpoint for Constant DeltaP adjustment.
DeltaP differential for Constant DeltaP adjustment.
23.67
23.69
Fan – Const. DeltaP
--------------- P23.68
Maximum reduction of
fan nominal speed: 20%
Resulting Min speed:
070 – (070X20%)= 056.0
Maximum reduction of nominal speed of the fan with Constant DeltaP adjustment
(determines the minimum speed of the internal fans).
Visible only if the fan setting is set according to air DeltaP.
23.68
Fan – Const. flow/DP
--------------- P23.70
Fan speed variation
at each step: 1.0%
Speed variation for each step of the fan during adjustment of the Constant DeltaP
and Constant Flow.
Visible only if the fan setting is set according to air DeltaP or air flow.
23.70
Fan – Const. flow/DP
Flow Sensor Adjustment
Real value 0000
Current value 0000
Set flow 0000
Store K? N
Calibration of the air differential transducer for the Constant Flow and Constant
DeltaP functions.
Fan
--------------- P23.72
Fans start at
Max speed: N
Start-up of the fan at maximum speed if the adjustment starts with the return
temperature higher than the corresponding setpoint
Visible only if the fan adjustment based on return temperature function is enabled.
23.72
Fan – Quick Restart
--------------- P23.81
Q. restart fan speed:
035%
Ventilation request during Quick Restart.
Visible only if the Quick Restart function is enabled.
23.81
