Mitsubishi Electric MELSEC iQ-R - Execution Example of the Write Function

136
1 FUNCTIONS
1.5 BACnet Request Function (Write Function)
Execution example of the write function
The following shows an execution example of the write function which writes a real number (1.0) to the PresentValue of an
AnalogOutput object (instance number: 10) in a BACnet device (instance number of a device: 3) from a BACnet module.
Assignment of an access block for writing
Assign an access block for writing in [Settings]  [BACnetRequest]  [Write] as follows.
For the assignment method, refer to the operating procedure from 1 to 4 described in the following section.
Page 132 How to use the write function
Item Description
BufferMemoryAddress 400
Qty. 1
