1 FUNCTIONS
1.12 Configuration Function
197
1
Settings
The following menu items can be set.
The settings are automatically saved in the internal memory. Refer to the following section.
Page 121 Backup Function
Network information
Set the network information of a BACnet module.
Operating procedure
1. Select [Settings]  [Network Information], and set the following items.
2. Click the [Update] button.
Menu item Setting method
Network Information Page 197 Network information
Basic Information Page 198 Basic information
BACnetObject Page 201 BACnet object
BACnetRequest Read Page 207 BACnet request (read)
Write Page 209 BACnet request (write)
BACnetMonitor Page 210 BACnet monitoring
COV Interaction Page 212 COV interaction
Event Interaction Page 214 Event interaction
Calendar Interaction Page 216 Calendar interaction
Who-Is Transmission Info. Page 218 Who-Is Transmission Info.
User Page 221 User
Item Description
BACnet PortNo Set a port number for BACnet communication.
NetworkNo Set a network number used for BACnet communication.
IPv4 IP Address Set the IP address of a BACnet module.
Subnet Mask Set the subnet mask of a BACnet module.
Default Gateway Set the default gateway of a BACnet module.
IPv6 Use IPv6 Select this when using IPv6.
IP Address Set the IP address of a BACnet module for IPv6.
Multicast Address Set the multicast address of a BACnet module for IPv6.
