1 FUNCTIONS
1.12 Configuration Function
1.12 Configuration Function
This function sets a BACnet module using a web browser.
For the method to log in to a BACnet module, refer to the following manual.
MELSEC iQ-R BACnet Module User's Manual (Startup)
When configuring settings, stop the operation of a BACnet module. (Page 224 Pause)
Screen configuration
Menu item Operating method/Setting method
BACnetObject Page 166 BACnetObject
BACnetRequest Read Page 190 Read
Write Page 191 Write
BACnetMonitor Page 192 BACnetMonitor
COV Interaction Page 193 COV Interaction
Event Interaction Page 194 Event Interaction
Calendar Interaction Page 194 Calendar Interaction
BACnetDevice Page 195 BACnetDevice
Log BACnet Communication Page 196 Displaying communication logs of BACnet
Message Page 196 Displaying BACnet communication errors
