ENGINE – Specifications
11-7
Items Nm
OIl return pipe (Turbocharger side) 9
Oil return pipe (Oil pan side – Head mark 7) 9
Oil return pipe (Oil pan side – Head mark 10) 13
Oil pipe 11
Oil pipe eye bolt (Cylinder head side) 16
Oil pipe eye bolt (Turbocharger side) 30
Water pipe 11
Water pipe eye bolt 41
Exhaust manifold (M8) 29
Exhaust manifold (M10) 49
Exhaust manifold (Turbocharger side) 59
Water pump and water hose
Water temperature sensor 29
Water temperature gauge unit 11
Water inlet fitting 24
Water outlet fitting (M6) 10
Water outlet fitting (M8) 13
Thermostat housing 24
Thermostat housing (Clamp) 11
Water inlet pipe (Cylinder block) 13
Water inlet pipe (Outlet fitting) 10
Water pump 14
Knock sensor 22
Rocker arms and camshaft
Camshaft position sensor 9
Camshaft position sensor cover 10
Camshaft position sensing cylinder 21
Camshaft position sensing support 13
Camshaft bearing cap 20
Oil delivery body 11
Cylinder head and valves
Cylinder head bolt [Tighten to 78 Nm and then completely before tightening to final torque
specification]
20 ! 90° + 90°
