App - 1 App - 1
MELSEC-Q
A
PPENDI
X
APPENDIX
Appendix 1 External dimension diagram
98(3.86)
90(3.54)
ERR.
RUN
CH4
CH3
CH2
CH1
QD60P8-G
CH5
CH6
CH7
CH8
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
1
2
27.4(1.08)
C
H
8
C
H
7
C
H
6
C
H
5
C
H
4
C
H
3
C
H
2
C
H
1
V+
V+
V-
V+
V-
V+
V-
V+
V-
V+
V-
V+
V-
V-
V-
V+
(FG)
5/12-
24VDC
Unit: mm (in.)
App

Mitsubishi QD60P8-G Specifications

General

Product Series	MELSEC-Q
Type	Positioning Module
Manufacturer	Mitsubishi Electric
Input Points	16
Input Type	Sink/source
Voltage Rating	24 V DC
Connection Type	Terminal block
Isolation	Photocoupler isolation
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 75°C
Weight	0.2 kg
Response Time	1 ms
Number of Control Axes	8 axes
External I/O	32 points (16 inputs, 16 outputs)
