2 - 5 2 - 5
MELSEC-Q
2 SYSTEM CONFIGURATION
2.3 How to Check the Function Version and the Software Version
This function version of the QD60P8-G and the software version of the
GX Configuration-CT can be checked in the following methods.
(1) Checking the function version of the QD60P8-G
(a) Method using the rated plate on the module side face
Check the alphabet at the end of "SERIAL"
Function version
Relevant regulation standards
(b) Method using the GX Developer
Check the alphabet at the end of "Product information" displayed on
"Module's Detailed Information" dialog box of GX Developer.
[Operation of GX Developer]
Click the [Diagnostics] [System monitor] menu and click the
Module's Detailed Information
button in the displayed window.
<Module's Detailed Information dialog box of GX Developer>
Function version
To Next Page
