MELSEC-Q
2 SYSTEM CONFIGURATION
(2) Support of the multiple CPU system
When using the QD60P8-G in a multiple CPU system, refer to the following
manual first.
• QCPU User's Manual (Multiple CPU System)
Write intelligent function module parameters to the control CPU of the QD60P8-G
only.
(3) Compatibility with online module change
The QD60P8-G supports the online module change function.
POINT
The QD60P8-G does not have the products of function versions A and B.
The products of function version C include the functions of the products function
versions A and B.
(4) Supported software packages
Relation between the system containing the QD60P8-G and software package is
shown in the following table.
GX Developer is necessary when using the QD60P8-G.
Software Version
GX Developer
GX Configurator-CT
Single CPU system Version 7 or later
Q00J/Q00/Q01CPU
Multiple CPU system Version 8 or later
Single CPU system Version 4 or later
Q02/Q02H/Q06H/Q12H/Q25HCPU
Multiple CPU system Version 6 or later
Single CPU system
Q02PH/Q06PHCPU
Multiple CPU system
Version 8.68W or later
Single CPU system
Q12PH/Q25PHCPU
Multiple CPU system
Version 7.10L or later
Version 1.14Q or later
Q12PRH/Q25PRHCPU Redundant CPU system Version 8.45X or later Version 1.16S or later
Single CPU system
Q02U/Q03UD/Q04UDH/Q06UDHCPU
Multiple CPU system
Version 8.48A or later
Single CPU system
Q13UDH/Q26UDHCPU
Multiple CPU system
Version 8.62Q or later
Single CPU system Q03UDE/Q04UDEH/Q06UDEH/
Q13UDEH/Q26UDEHCPU
Multiple CPU system
Version 8.68W or later
Version 1.25AB or later
If installed in a MELSECNET/H remote I/O station Version 6 or later Version 1.14Q or later
To Next Page
