App - 41 App - 41
MELSEC-Q
APPENDIX
(4) Fuse blown module
Number Name Meaning Explanation
Set by
(When set)
Corresponding
ACPU
D9
Applicable
CPU
SD1300 D9100
SD1301 D9101
SD1302 D9102
SD1303 D9103
SD1304 D9104
SD1305 D9105
SD1306 D9106
SD1307 D9107
SD1308 New
SD1309
to
SD1330
New
SD1331
Fuse blown
module
Bit pattern in units of
16 points, indicating
the modules whose
fuses have blown
0: No blown fuse
1: Blown fuse present
• The numbers of output modules whose fuses have blown are
input as a bit pattern (in units of 16 points).
(If the module numbers are set by parameter, the parameter-set
numbers are stored.)
• Also detects blown fuse condition at remote station output
modules
1514131211109876543210
0
0
0
1
(YC0)
000 00000000
1
(Y80)
SD1300
00
1
(Y1F0)
0 0 00000000
1
(Y1A)
SD1301
00
00
1
(Y1F
B0)
00000000
SD1331
000
1
(Y1F
30)
0
Indicates a blown fuse
• Not cleared even if the blown fuse is replaced with a new one.
This flag is cleared by error resetting operation.
S (Error)
New
+Rem
SD1350
to
SD1381
External
power
supply
disconnecte
d module
(For future
expansion)
Bit pattern in units of
16 points, indicating
the modules whose
external power supply
has been
disconnected
0: External power
supply
disconnected
1: External power
supply is not
disconnected
The module number (in units of 16 points) whose external power
supply has been disconnected is input as a bit pattern.
(If the module numbers are set by parameter, the parameter-set
numbers are used.)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SD1350
SD1351
0001000 000000001
00
1
0 0 00000000
1
00
SD1381 00 1 0 0000 00000010
Indicates a blown fuse
S (Error) New
QCPU
Remote
(5) I/O module verification
Number Name Meaning Explanation
Set by
(When set)
Corresponding
ACPU
D9
Applicable
CPU
SD1400 D9116
SD1401 D9117
SD1402 D9118
SD1403 D9119
SD1404 D9120
SD1405 D9121
SD1406 D9122
SD1407 D9123
SD1408 New
SD1409
to
SD1430
New
SD1431
I/O module
verification
error
Bit pattern, in units of
16 points, indicating
the modules with
verification errors.
0: No I/O verification
errors
1: I/O verification error
present
• When the power is turned on, the module numbers of the I/O
modules whose information differs from the registered I/O
module information are set in this register (in units of 16 points).
(If the I/O numbers are set by parameter, the parameter-set
numbers are stored.)
• Also detects I/O module information
15
14
13
12 11
10 9 8
7
65
4
3
21
0
000 000 0000000
SD1400
00 0 00000000
SD1401
00
0 0 0000 000
SD1431
0000
00
00
00
1
( )
X Y
1FE0
1
( )
1
( )
X Y
190
X Y
0
Indicates an I/O module verification error
• Not cleared even if the blown fuse is replaced with a new one.
This flag is cleared by error resetting operation.
S (Error)
New
+Rem
