5
1 Before Using This Product
No. 99MAF029B
A Shows the result of the tolerance judgment.
Tips
For details, "3.2 Judging the
Tolerance" (page 38)
B Turns the power on or off.
C Measures the inner diameter.
Tips
For details, "2.3 Measuring the
Inner Diameter" (page 21)
D Measures the outer diameter.
Tips
For details, "2.4 Measuring the
Outer Diameter" (page 25)
E Measures the maximum, minimum, and
displacement values (maximum – minimum =
displacement) of a horizontal plane.
Tips
For details, "2.5 Measuring the
Plane Displacement (Plane Scanning
Measurement)" (page 29)
F Changes the origin between ABS and INC
settings.
G Changes the setting for units between inches
and millimeters (only on models that support
inches).
H Sets a value for the origin.
I
Changes numbers and settings. Press
to confirm an operation.
Tips
Press and hold to reverse
the counting direction: Moving
the probe upwards decreases
the value, and moving the probe
downwards increases the value.
Press and hold the button again to
return to normal.
If you reversed the counting
direction, follow the procedure in
"1.4.1 Origin Setup" (page
10) to reset the origin.
J Cancels an operation.
K Used to change settings for a specific
application, such as changing the
measurement resolution.
Tips
For details, "3 Specific Usage
Applications" (page 31)
L Holds a measurement in the display and
outputs the measurement results to external
devices.
Tips
For details, "3.5 Holding the
Displayed Measurement Results"
(page 44) and "3.9 Outputting
Measurement Results to an External
Device" (page 47)
