1 Before Using This Product
No. 99MAF600B
z
Setting a point other than the surface plate as the reference
As an example, the procedure for setting the reference to [+25.000 mm] using a 25 mm gauge block is
explained below.
Tips
You can perform the settings using the dial test indicator or the dial indicator instead of the probe.
1
Press .
2
Press to make [+] ash.
If [–] is displayed, press or to change it to [+].
3
Repeatedly press until the value in the 10s place ashes.
4
Press or to display [2].
