MKS 649B - Physical Specifications

Dimensions Chapter Two: Installation
14
5.29
(134.4)
5.50
(139.8)
4-VCR: 6.66 (169.2)
8-VCR: 7.11 (180.6)
Type 649
Figure 1: Front View of the Type 649 Controller
Figure 2: Back View of the Type 649 Controller
Side View
The flow meter adjustments are located on the inlet side of the 649 controller.
