MKS 649B - Initial Configuration; Table 8: Initial Configuration

Initial Configuration Chapter Two: Installation
20
Initial Configuration
The 649 pressure controller is shipped from the factory with the configuration listed in Table 8.
Initial Configuration
Feature Setting Options
Pressure Control Downstream no option
Set Point Input* 0 to 10 V 0 to 5 V
Pressure Output 0 to 10 V 0 to 5 V
Flow Output 0 to 5 V no option
Trip Point A
Setting
Action
100% F.S.
Trip high (TH)
1 to 100% F.S.
Trip low (TL)
Trip Point B
Setting
Action
1% F.S.
Trip low (TL)
1 to 100% F.S.
Trip high (TH)
P Term Position 0 8 settings (0 through 7) on a 10 position dial
(8 repeats setting 0; and 9 repeats setting 1)
I Term Position 0 10 settings, 0 through 9
* Input must match the pressure output signal range
Table 8: Initial Configuration
