Program
item
Function
Scope of the values
(default values are printed in bold)
P8
Clock address for
IR remote control
and the serial
protocols
1-99
0-31, L (listen only) at SI version
0-15 - at WTD version
P9
IR controller
autolock
1-60, U ("automatic lock" is OFF)
Time in minutes for "automatic lock" since the last depression of
button on the IR unit
P10
Time format display
1-2
1
time with leading zero
2
time without leading zero
P11
Date format display
1-2
1
date with leading zero
2
date without leading zero
P12
Temperature
format display
°C
°F
P13
Protocol for RS232
and RS485
communication
1 - IF482
2 - Supervised RS485
3 - DC master
4 - DC slave
5 – TP … RS485 master
6 – TP … RS485 listener
7 – DC2 slave
8 – T741x master
9 – T741x listener
10 – ITRON 2000
11 – TPHP RS485 Master
12 – TPHP RS485 Listener
P14
Modulation speed
for RS232 and
RS485
1-7
1
1 200 Baud
2
2 400 Baud
3
4 800 Baud
4
9 600 Baud
5
19 200 Baud
6
38 400 Baud
7
57 600 Baud
P 15
Transmission
parameters for
RS232 and RS485
Number of data bits
8
7
P 16
Number of stop bits
1
2
P 17
Parity
n no parity
o odd
E even
P 18
IP mode
0
NTP, PoE: IPv4 / IPv6 dualstack
WiFi: not supported
1
NTP, PoE: IPv4
WiFi: IPv4
2
NTP, PoE: IPv6
WiFi: not supported
