5 The clock menu table
Program
item
Function
Scope of the values
(default values are printed in bold)
P0
Display brightness
1-30, A (automatic adjustment, without the possibility of
changing in normal display mode)
The maximum brightness setting in manual mode can reduce
the life cycle of the LED displays in the long run. We
recommend leaving the brightness control to "auto" mode
(default value).
P1
Time display format
24 h, 12 h
P2
Time constants for
automatic data
switching over
1-6, U, 0
1
continuous display of time
2
continuous display of date
3
continuous display of temperature
4
continuous display of stop watch
5
display sequence: time 6 sec, date 3 sec.
6
display sequence: time 8 sec, date 3 sec, temp. 3 sec.
U*
time constants set up by user, in seconds for each specific
displayed data
0
automatic switching over disabled
P3
Time zone of
synchronization
source
0 - 64, A (automatically)
P4
Type of
synchronization
source
(check Line type
jumper JP11
setting, see the
chapters 2.8
and 10 for more
information)
1 - 10, A (automatically)
A*
auto detection, applicable for: DCF, the Mobatime serial
code, MOBALine, WDT, IRIG-B or NTP
1*
autonomous operation without synchronization
2*
synchronization by DCF signal
3*
the MOBATIME serial code
4*
MOBALine
5*
24 V DC impulses, at minute intervals
6*
24 V DC impulses at half minute intervals
7*
24 V DC impulses at second intervals
8*
DCF-FSK, IRIG-B Standard, IRIG-B 123, IRIG-B DIEM,
AFNOR A, AFNOR C
9*
RS232
10*
RS485
11*
Internal GPS receiver
12*
Active DCF code
P5
Impulse line
processing mode
1-4
1
polarized impulses, synchronization and time adjustment
2
polarized impulses; time synchronization only
3
non-polarized impulses, synchronization and time
adjustment
4
non-polarized impulses; time synchronization only
P6
Time zone for
MOBALine or time
zone server
MOBATIME
1-20, 0 (off) – for MOBALine synchronization
or
1-15, 0 (off) – for NTP synchronization
P7
Time zone of
displayed time and
date
0 - 64, A (automatically), U* (user time zone, see chap. 9.5)
U1-U7 (preconfigured time zone entry by MOBA-NMS)
