© MOBATIME 27 / 52 800693.16
6 Control of the stopwatch via keyboard
The operation of the stopwatch is controlled and the device is adjusted using three
pushbuttons on the connected keyboard. The keyboard cable must be connected to the CTRL
plug connector.
Abbreviations used for the key strokes
PB1L, PB2L pushing of the pushbutton for a period of
more than 1 second
PB1S, PB2S, PB3S short-time pushing of the pushbutton
Function of the pushbuttons in the “Stopwatch“ mode
PB2S indication switch over:
time - date - temperature - stopwatch - time
PB2L stopwatch menu
PB3S, PB1S, PB1L according to the stopwatch mode setup
6.1 The stopwatch menu
The stopwatch menu is entered by long pushing of the PB2 pushbutton (stopwatch
must be displayed). The parameter adjustment is to be performed according to the
menu table (chapter 8).
Function of the pushbuttons in the “Stopwatch Menu“ mode
PB1S move to another menu item
PB1L storage of the parameters; return to the stopwatch display mode when
counting up from zero; or entry into the initial time setting mode when
counting down
PB2S increase of the current value, in steps of 1
PB2L continuous increase of current value
6.2 Setting of the initial time for counting down
When counting down is selected, the initial time setting mode is entered from the
stopwatch MENU or directly from the “Stopwatch” display mode by pushing the PB1L
button. The item to be set is blinking.
By pushing the PB2S button is the adjusted value increased in steps of 1, by pushing
the PB2L button will be the value continuously increased. By pushing PB1S move to
the next item. By pushing the PB1L save the setting and return to “Stopwatch” display
mode.
Enter the data in the following order depending on the item S2 setting (counting unit):
By pushing the PB1L button, the entered values are stored and the clock returns to the
“Stopwatch” display mode.
<Minute>:<Second>.<Hundredths of
second>
<Hours>:<Minutes>:<seconds>.
