© MOBATIME 29 / 52 800693.16
7.2 Setting of initial time for counting down
When counting down is selected, the initial time setting mode is entered from the
stopwatch MENU or directly from the “Stopwatch” display mode by pushing the PB1L
button. The item to be set is blinking.
Enter data in following order depending on the item S2 setting (counting unit):
By pushing the OK button, the entered values are stored and the clock returns to the
“Stopwatch” display mode. By pushing ESC, the clock returns without storing.
7.3 Switching contact
When counting down mode is applied the switching contact can be used (only for
certain types of clocks), which switches at zero-crossing. It is possible to control an
external device such as sound devices. There is normally open contact (NO), normally
closed contact (NC) and common contact (COM) on the relay port (JP21) available.
<Minutes>:<Seconds>.< Hundredths
of second >
<Hours>:<Minutes>:<Seconds>.
