Description
0112-0127 B 17
Covers and Instrument Panels
Top Cover
The instrument is protected by a molded plastic housing. The large top
cover protects the fluidics module and the exposed portions of the
detection module.
Figure 1-5: Lifting Off the Top Cover
Note: The top cover can be lifted back, as shown in the figure below,
for certain limited troubleshooting procedures. See
Opening the
Instrument on page 137.
Note: To achieve optimal performance during readings, you must
operate the system with the top cover in place.
FlexStation_manual.book Page 17 Tuesday, June 25, 2013 10:22 AM
