Monarch 9906 - ENQ Reference Table - Byte #2

7-2 Packet Reference Manual
ENQ Reference Table - Byte #2
Char
Const.
OFF
Const.
ON
Comp.
Failure
Corr.
Error
Online
Data Error
Busy Active Online
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
@ 0 1 0 0 0 0 0 0
A 0 1 0 0 0 0 0 1
B 0 1 0 0 0 0 1 0
C 0 1 0 0 0 0 1 1
D 0 1 0 0 0 1 0 0
E 0 1 0 0 0 1 0 1
F 0 1 0 0 0 1 1 0
G 0 1 0 0 0 1 1 1
H 0 1 0 0 1 0 0 0
I 0 1 0 0 1 0 0 1
J 0 1 0 0 1 0 1 0
K 0 1 0 0 1 0 1 1
L 0 1 0 0 1 1 0 0
M 0 1 0 0 1 1 0 1
N 0 1 0 0 1 1 1 0
O 0 1 0 0 1 1 1 1
P 0 1 0 1 0 0 0 0
Q 0 1 0 1 0 0 0 1
R 0 1 0 1 0 0 1 0
S
0
1
0
1
0
0
1
1
T 0 1 0 1 0 1 0 0
U 0 1 0 1 0 1 0 1
V 0 1 0 1 0 1 1 0
W 0 1 0 1 0 1 1 1
X 0 1 0 1 1 0 0 0
Y 0 1 0 1 1 0 0 1
Z
0
1
0
1
1
0
1
0
[ 0 1 0 1 1 0 1 1
\ 0 1 0 1 1 1 0 0
] 0 1 0 1 1 1 0 1
^ 0 1 0 1 1 1 1 0
_ 0 1 0 1 1 1 1 1
` 0 1 1 0 0 0 0 0
Note: A “1" indicates the bit is turned on. A ”0" indicates the bit is off.
