Monarch 9906 - Sample Aztec Packet; Sample Intelligent Mail Packet

Samples A-9
Sample Aztec Packet
Aztec is a two-dimensional bar code symbology consisting of square modules arranged around a
square bulls eye pattern. For more information about the Aztec bar code, refer to the ANSI/AIM
BC13 ISS - Aztec Code Specification from AIM Global.
{F,1,A,R,E,200,200,"TEST" |
B,1,25,V,20,20,37,7,0,0,L,0 |
R,53,0,0,0,1,"" | }
{B,1,N,1 |
1,"Monarch Brand Printers" | }
Sample Intelligent Mail® Packet
For the Intelligent Mail® bar code, the maximum number of characters is 31, including commas
between the data. For more information, refer to the USPS® Intelligent Mail® Specification.
{F,1,A,R,G,1218,812,"intmail"|
B,1,35,V,100,100,24,0,0,8,L,0|}
{B,1,N,1|
1, "11,222,333333,444444444,55555555555"| }
In the above sample, the batch data indicates the following:
Batch Data Description
11
Bar code ID:
First digit = 0 to 9; Second digit = 0 to 4
222
Special Services:
Range: 000 to 999
333333
Mailer ID: Range: 000000 to 999999
444444
Serial Number:
Range: 000000000 to 999999999
555555555
Delivery Point ZIP code:
0, 5, 9, or 11-digit ZIP code
