2-28 Packet Reference Manual
Defining the RFID Setup Packet
Use the RFID setup packet (X) to set the RFID values. The packet includes parameters for
protocol, write attempts, read power, write power, and signal adjust for legacy purposes only.
The printer does not support protocol, write attempts, read power, or signal adjust. Values
entered for these parameters do not change printer settings, but they must be accepted values or
an error occurs.
You can use the Monarch® RFID Printer Setup Utility to configure your printer (power level, print
and supply position, etc) for your RFID supplies. Find this Web-based utility at
http://www.servisource1.com/prnutil/rfidsetup/
.
Syntax {I,X,protocol,write_attem,read_power,write_power,
signal_adjust | }
X1. X RFID Setup Packet.
X2. protocol This printer is C1G2 protocol only, use 0. Accepted values 0 to 4.
X3. write_attem Write attempts, use 3. Accepted values 1 to 5.
X4. read_power Read power, use -7. Accepted values -7 to 27.
X5. write_power Write or RF Power. The amount of power to read and write (program)
an RFID tag. The range is -7 to 27; -7 is the default.
X6. signal_adjust Signal adjust, use 2. Accepted values 1 to 6.
Example {I,X,0,3,10,11,2 | }
Sets the RF power level to 11.
