Monarch 9906 - Page 120

7-4 Packet Reference Manual
ENQ Reference Table - Byte #3
Char
Const.
OFF
Const.
ON
Low
Battery
Format
Error
Waiting to
Dispense
Label
Ribbon
Fault
Stock
Fault
Online
Error
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
@ 0 1 0 0 0 0 0 0
A 0 1 0 0 0 0 0 1
B 0 1 0 0 0 0 1 0
C 0 1 0 0 0 0 1 1
D 0 1 0 0 0 1 0 0
E 0 1 0 0 0 1 0 1
F 0 1 0 0 0 1 1 0
G 0 1 0 0 0 1 1 1
H 0 1 0 0 1 0 0 0
I 0 1 0 0 1 0 0 1
J 0 1 0 0 1 0 1 0
K 0 1 0 0 1 0 1 1
L 0 1 0 0 1 1 0 0
M 0 1 0 1 1 0 0 1
N 0 1 0 0 1 1 1 0
O
0
1
0
0
1
1
1
1
P 0 1 0 1 0 0 0 0
Q 0 1 0 1 0 0 0 1
R 0 1 0 1 0 0 1 0
S 0 1 0 1 0 0 1 1
T 0 1 0 1 0 1 0 0
U 0 1 0 1 0 1 0 1
V 0 1 0 1 0 1 1 0
W 0 1 0 1 0 1 1 1
X 0 1 0 1 1 0 0 0
Y 0 1 0 1 1 0 0 1
Z 0 1 0 1 1 0 1 0
[ 0 1 0 1 1 0 1 1
\ 0 1 0 1 1 1 0 0
] 0 1 0 1 1 1 0 1
^ 0 1 0 1 1 1 1 0
_ 0 1 0 1 1 1 1 1
` 0 1 1 0 0 0 0 0
Note: A “1" indicates the bit is turned on. A ”0" indicates the bit is off.
