3 Mechanical and Electrical Installation NICE5000 User Manual
- 60 -
Controller Model
Power of
Adaptable
Motor (kW)
Max.
Resistor
(
Ω
)
Min.
Resistance
(
Ω
)
Power of
Regen.
Resistor
(W)
Braking Unit
220-NICE-LWX-4055-A/B/C0 37.0 4.5 3.5 11000 MDBUN-60-2T x 2
Three-phase 380 V, range: -15% to 20%
NICE-LWX-4002-A/B/C0 2.2 290 230 600
Built-in
NICE-LWX-4003-A/B/C0 3.7 170 135 1100
NICE-LWX-4005-A/B/C0 5.5 115 90 1600
NICE-LWX-4007-A/B/C0 7.5 85 65 2500
NICE-LWX-4011-A/B/C0 11 55 43 3500
NICE-LWX-4015-A/B/C0 15 43 35 4500
NICE-LWX-4018-A/B/C0 18.5 34.0 25 5500
NICE-LWX-4022-A/B/C0 22 24 22 6500
NICE-LWX-4030-A/B/C0 30 20 16 9000
NICE-LWX-4037-A/B/C0 37 16.0 13 11000 MDBUN-60-T
NICE-LWX-4045-A/B/C0 45 14.0 11 13500 MDBUN-60-T
NICE-LWX-4055-A/B/C0 55 12.0 10 16500 MDBUN-90-T
NICE-LWX-4075-A/B/C0 75 16 x 2 14 x 2 12000 x 2 MDBUN-60-T x 2
NICE-LWX-4090-A/B/C0 90 14 x 2 13 x 2 13500 x 2 MDBUN-60-T x 2
NICE-LWX-4110-A/B/C0 110 12 x 2 9 x 2 18000 x 2 MDBUN-90-T x 2
NICE-LWX-4132-A/B/C0 132 13.5 x 3 10.5 x 3 14000 x 3 MDBUN-90-T x 3
NICE-LWX-4160-A/B/C0 160 12 x 3 9 x 3 18000 x 3 MDBUN-90-T x 3
Note
•
The preceding conguration takes the synchronous motor as an example. The asynchronous
motor has poor energy transfer efciency, and you can reduce the power of the regen. resistor
or increase the resistance of the regen. resistor.
•
It is recommended that you select the regen. resistor closest to the minimum resistance.
•
"x 2" indicates that two sets are required. Take NICE-LWX-4110 as an example: "9 x 2, 18000
x 2, MDBUN-90-T x 2" indicates that two sets of (9 Ω, 18000 W) regen. resistor + MDBUN-
90-T braking unit are connected in parallel to the controller. "x 3" indicates that three sets are
required.
