Moog Infinity User Manual

Innity
®
Enteral Feeding Pump Operator’s Manual
14
2. DIRECTIONS FOR USE
Step 4:
Press the + or - key to change the rate to 50 ml/hr.
Hold down either key to change rapidly (Figure 2-19).
Step 5:
Press the RATE/DOSE key to display dose. Press the +
or - key until a dose of 100 ml is displayed (Figure 2-20).
Step 6:
Press the FEED INT key to display the feed
interval setting. Press the + or - key until
6.00 hr is displayed (Figure 2-21).
NOTE: The amount of time to complete a rate and
dose combination can be gured by dividing the
dose by the rate (Dose/Rate = Time). The number of
hours to be programmed as the feed interval is the
amount of time to deliver the dose plus the amount
of time pump should pause. Example: 100 ml divided
by 50 ml/hr equals 2 hours for feeding delivery, plus a
pause of 4 hours equals a feeding interval of 6 hours
(100 ml ÷ 50ml/hr = 2 hours running + 4 hours pause
= 6 hours from feeding start time to start time).
Pump will calculate number of hours it will take to
deliver the rate and dose combination. When the
FEED INT key is pressed the rst available value
will be compatible with that combination. In this
example the rst available value will be 2.00 hr.
NOTE: Feed interval is displayed in hours and
minutes, i.e. 5.10 = 5 hours and 10 minutes.
NOTE: Feed interval cannot be programmed
if rate and dose combination requires
more than 24 hours to deliver.
Step 7:
Connect end of disposable set to patient’s enteral feeding tube. (Figure 2-22).
Figure 2-19 Program
Rate to 50 ml/hr
Figure 2-20 Program
Dose to 100 ml
Figure 2-21 Program
Feed Interval 6.00 hr
Figure 2-22 Connect disposable
set to feeding tube

Moog Infinity Specifications

General

Model	Infinity
Type	Infusion Pump
Occlusion Pressure Settings	Low, Medium, High
Alarms	Occlusion, Low battery
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Manufacturer	Moog
Infusion Modes	Continuous, Intermittent
Display	LCD
Compatibility	Standard infusion sets
