Tip: Before removing the mounting template after cutting or drilling the required holes, mark or
otherwise make note of the direction the orientation arrow is facing. This will help you to align the
camera body in the same orientation when installing.
When installing the camera to a wall, make sure that the orientation arrow is facing up, as shown in the
diagram below.
Mounting in the Correct Orientation 18
