7. Install the grommet into the cable entry hole on the camera base. Make sure the grommet flange is
securely seated on the inside and outside of the cable entry hole.
8. Use the cable clip to hold the Ethernet cable in the correct position.
Connecting Cables
Refer to the diagrams in the Overview section for the location of the different connectors and status LEDs on
the camera base.
