In-Ceiling Mount Installation
Required Tools and Materials
The following tools are required to complete the installation but are not included in the package:
l Appropriate tool for cutting the entry hole in the mounting surface
l Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using
Power over Ethernet
Camera Package Contents
Ensure the in-ceiling mounted camera package contains the following:
l Avigilon H5A Fisheye In-Ceiling Camera
l In-ceiling mounting adapter
l In-ceiling camera cover
l Star-shaped screwdriver
l Power terminal block
l 3-hole rubber grommet — for multi-cable installations.
l Single-hole rubber grommet — for installations with a single Ethernet/PoE cable.
l RJ45 grommet piercing cap — for use with single-hole rubber grommet only
Installation Steps
Complete the following sections to install the device.
Mounting in the Correct Orientation
The H5A Fisheye camera provides 360° views of large areas. Because of the 360° view, it is not obvious
which part of the camera should be facing up when installed on a wall. To help with this, the mounting
template and the camera body have an up orientation arrow printed on them to signal which end should be
facing up.
When installing the camera on a ceiling, the orientation arrow can go in any direction.
Tip: Before removing the mounting template after cutting or drilling the required holes, mark or
otherwise make note of the direction the orientation arrow is facing. This will help you to align the
camera body in the same orientation when installing.
When installing the camera to a wall, make sure that the orientation arrow is facing up, as shown in the
In-Ceiling Mount Installation 32
