6. Repeat the previous step on the other side. Make sure both clamps are level and horizontal.
Installing the Camera Base into the Mounting Adapter
After you install the mounting adapter, mount the camera base to the adapter.
1. Attach the lanyard on the mounting adapter to the anchor on the camera base.
2. Pull the required cables through the cable entry hole on the camera base.
3. Align the up orientation arrow on the camera base with the arrow on the in-ceiling adapter. Align the
Installing the Camera Base into the Mounting Adapter 37
