Motorola APX 2000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-39
GPIO_1_DP_TXDC_FILLREQ J2-11
SW_5+ J2-12
GCAI_1WIRE_5V J2-13
SW_5+ J2-14
GPIO_4_CTS_KEYFAIL_FILLCL
K
J2-15
TX_RX_LED_AMBER J2-16
GPIO_0 J2-17
TX_RX_LED_RED J2-18
GND J2-19
TX_RX_LED_GREEN J2-20
EXT_MIC_NEG_DP J2-21
GND J2-22
EXT_MIC_POS_DP J2-23
MIC+ J2-24
GND J2-25
MIC- J2-26
EXT_SPKR_POS_DP J2-27
GND J2-28
EXT_SPKR_NEG_DP J2-29
VBUS2 J2-30
GND J2-31
VBUS2 J2-32
NFC J2-33
GND J2-34
GND J2-G1
GND J2-G2
GND J2-G3
GND J2-G4
Test Place
Front Kit Flex
Signal Name Pin #
