Motorola APX 2000 Detailed Service Manual

7-40 Troubleshooting Tables: List of Board and IC Signals
Test Place
Front Kit Flex
Signal Name Pin #
GND J3-1
V_2.775D J3-2
F_DISP_RW J3-3
GND J3-4
F_DISP_DATA_1 J3-5
F_DISP_DATA_3 J3-6
F_DISP_DATA_5 J3-7
F_DISP_DATA_7 J3-8
GND J3-9
F_DISP_DATA_CMD J3-10
GND J3-11
SW_5+ J3-12
MAIN_DISPLAY_LED3 J3-13
F_DISP_BD_ID J3-14
GND J3-15
GND J3-16
MAIN_DISPLAY_LED4 J3-17
MAIN_DISPLAY_LED2 J3-18
MAIN_DISPLAY_LED1 J3-19
OMAP_RESET J3-20
GND J3-21
F_DISP_RW_EN J3-22
GND J3-23
F_DISP_DATA_6 J3-24
F_DISP_DATA_4 J3-25
F_DISP_DATA_2 J3-26
F_DISP_DATA_0 J3-27
GND J3-28
V_EXT_1.85 J3-29
GND J3-30
